Hydraulic Folding (1- and 2-Section Models)


Hydraulically fold and unfold the SuperRoller without moving the tractor. On one- and two-section models, a hydraulic hitch simply rotates both rollers between transport and field positions. The rollers lock into place with 2-inch-diameter pivot pins for maximum durability.

Hydraulic Folding (3-Section Models)


Hydraulically fold and unfold the SuperRoller without moving the tractor. On three-section models, the end sections fold forward for transport mode. The rollers lock into place with 2-inch-diameter pivot pins for maximum durability.

Rigid Frame


The Field Tested Tough frames on Summers land rollers are designed to outlast any other product on the market.

Heavy Duty Drums


Summers land rollers are available with both 36- and 42-inch diameter drums. For extreme durability and proper weight, the 36-inch drums (available on 50- and 84-foot land rollers) have 17/32-inch wall thickness, and 42-inch drums have 9/16-inch wall thickness – the thickest in the industry.

Oversized Bearings


The rollers are equipped with the largest bearing shafts available. These 3-1/2-inch 1045 cold-rolled steel shafts are machined down to accommodate 2-1/2-inch relubricable bearings with ductile cast housings, providing long-lasting performance.

Mud Scrapers


Each roller features a mud scraper to keep it clean and functioning properly.
